Zusammenfassung Messwiderstände
Folgende Formeln kommen im Kapitel Messwiderstände als Sensoren vor:
\[
\begin{gathered}
R_{\mathrm{PT100}} = 100\,\Omega + 0{,}4\,\frac{\Omega}{°\mathrm{C}} \cdot T \\[6pt]
\text{Betrieb an einer Stromquelle: } U_{\mathrm{PT100}} = R_{\mathrm{PT100}} \cdot I_0 \\[6pt]
\text{Linearer Messwiderstand allgemein: } R_{\mathrm{Mess}} = R + \Delta R \\[6pt]
\text{Betrieb am Spannungsteiler: } U_S = U_0 \cdot \frac{R_{\mathrm{PT100}}}{100\,\Omega + R_{\mathrm{PT100}}}
\end{gathered}
\]
